Jun 15
50 MHz

15 June 2018 Good activity in FT8 within Europe, nothing else outside EU so far.
14 June 2018 Again around 06 UT signals from Japan and BD3BDB (OL69) up to -12 dB. Nothing in other modes - No activity in JT65. Later Band was open to D4 and S01.
13 June 2018 FT8: Several stations from Japan were seen at maximum -16dB around 06 UT. The only other DX seen was S01.
12 June 2018 FT8: Stations from HI, VP2, FM5, 9Y, PJ4 and PV8 were seen with partially strong signals. Did not call because all were worked in CW before.
11 June 2018 DXwise only WP4 was heard
10 June 2018 In FT8: Many EU and WP4 and some W4 from Florida heard. Some CW QSOs.
09 June 2018 Hrd FT8: UN3GX and all of Europe. Worked 7X2KF (JM06) for new grid in CW. This was followed by a number of CW contacts in EU.
08 June 2018 Lots of EU FT8 activity.
07 June 2018 FT8 hrd some stations K1, W3, W4 aereas quite weak only.
06 June 2018 FT8: worked W4SO & N3XX and heard some more from the same aerea
05 June 2018 No DX heard, only EU in FT8.
04 June 2018 FT8 wkd: HI3T (FK49) Hrd FT8: N4, W5 and XE2JS. In CW HI3T was heard strong.
03 June 2018 One CW contact. Hrd CW: TZ4AM Hrd FT8: WP4, 9K2, PZ5, VP2, PV8, 4X, A92 and S01.
02 June 2018 Lots of stations received in FT8. Best were WP4G and UN6T. Called SU1SK in SSB, who was very strong, but others were stronger than me. Some few CW QSOs.
01 June 2018 Some EA and CT received in CW

Posted by Christoph Petermann

Jun 2
50 MHz
(Digital signals will only be reported, when worked or something extraordinary received. The receiver is running constantly now in FT8 or JT65 modes)
30 May 2018 Lots of European (FT8) plus S01, EA8 and D4.
29 May 2018 FT8 receiver running all day. Only lots of Europeans received.
28 May 2018 Worked some F and EA5 in CW. Later caught C31CT in CW as well. Lots of activity in FT8, no QSO.
27 May 2018 FT8 worked a few OH3 and OH4. Long CQ in CW - no result.
26 May 2018 Worked D41CV (FT8) Hrd (FT8) : TA, EA8, S01 and CW TY2AC
25 May 2018 After a CQ JR6FC (PL36) returned - no QSO.
24 May 2018 Worked S01WS in FT8
23 May 2018 Worked LZ (CW) and some stations in FT8 Hrd: 7X, 9K
22 May 2018 First JA station ever seen in FT8. Some CW contacts to LZ, SV ..
5 May 2018 Life in CW :-) worked I8, IT9 and 9H1
3 May 2018 FT8: Italy and Sicily worked
2 May 2018 France and Romania worked via SporadicE. Only FT8 Digital mode seen. Absolutely no CW or SSB signals. :-(

Posted by Christoph Petermann

May 3
50 MHz
By the end of April some weak SporadicE signals were heard. But no contact made.

Still very busy with other things than radio. I will take down the tower in the next days for some work to be done on it like cleaning, painting and fixing the coaxes. The 2m antenna shall go up again.

Posted by Christoph Petermann

Apr 17
My satellite receiver "slept" for a while. Together with my son Michael we got the system running again. For this moment the receive system consists of a R2FX scanning receiver specially for this purpose connected to a crossed dipole antenna below the roof. The receiver AF output is fed into a PC with WxToImg (licensed version) running. The latest images are uploaded to this site, when we have the receiver running.
The antenna preamplifier seems to be defective. Thus the receive power is not as good, as it used to be. This has to be repaired.

DF9CY's weather images

Posted by Christoph Petermann

Apr 1
Just some activity on 40m in CW and the digital modes JT65/FT8. The influenca caught me and my spare time is filled with other things in the moment which keep me away from amateur radio.
But the Sporadic-E season is coming closer and I will have an eye on it early this year.

Posted by Christoph Petermann

Dec 4
CQWW DX CW Contest on 25/26 November 2017
Last weekend turned out to be a very quiet one and a view on the calender told me: Hey, there is the CQWW CW coming up. I decided to give out some points and did some preparations. My "surplus" FL2100 is a little bit broken, and so I had to go with about 75 watts only into my full size dipole on 40m which is up 9,5m in the middle with one side hanging down now. This is because my new neighbour did not like the antenna to be fixed at a pole in his garden anymore. It had been there for the last 15 years or so. So I took a pole of the garden fence - it is ours.
So Win-Test was prepared and I went in the room to make some contacts from time to time. It was more difficult than it has been in the WAG contest some weeks ago, where I made 350 QSOs almost in a row. I ended up with exactly 200 valid contacts (1 dupe) in 46 DXCC countries and 10 zones.
Why was it so much more difficult than the WAG? In the Worked All Germany everone is fixed to work a German station, but in CQWW you have to concur with everyone everywhere with mainly high power, that I did not have. Sometimes I thought, my radio did not work, because noone returned to CQs for quite a while, but out of a sudden I got 12 stations in five minutes. Sometimes I could not get stations beeing really loud, even when nobody returned their CQs. On the other hand I got weak US stations that were barely audible. But this is CQWW. And I am happy with the result.
On 4 Dec I sent the log out to the contest crew.

Posted by Christoph Petermann

Nov 3
You probably do not see it, but the whole site is rearranged and broken links are working correctly now. Especially the Subdomains I am running here in subdirectories had a lot of problems. They are all solved now.

My music bands site FolkZeit.
My private music site Christoph's Music

The FolkZeit page is a CMS (Content Management System) named Kirby. It uses PHP but is running in a file system instead a MySQL database.

The other site is a more simple HTML/CSS template, but I am thinking on changing it to Kirby (or GRAV, the concurrent product) in the future.

This page is realized with a blogging system called Serendipity, whereas the subpages are made with HTML/CSS again.

Have fun.

Posted by Christoph Petermann

Oct 24
50 MHz
24 October 2017 Worked some Aurora contacts to Norway and Sweden; hrd OH and GM.

7 MHz
23/24 October 2017
WAG (Worked All Germany) contest. I took some time and made 343 valid QSOs (checked) on 40m only and pure CW. I used the TS590s with about 80w of output. 41 DXCCs were contacted; so not bad at all for this very low installed dipole antenna.

Posted by Christoph Petermann

Sep 30
50 MHz
8 Sep 2017 Big aurora opening. I was home late, but worked about 30 stations up to 1450 km.

I have been very busy with my new job, so I was not QRV often.

Posted by Christoph Petermann

Sep 11
Working all the DX throughout the past months was somewhat annoying when I wanted to make digital (JT65 or FT8) contact right after having switched on the transceiver, the Kenwood TS590s. This happens, when the main reference oscillator is cold and has to warm up for some time. I experienced a frequency drift of over 120 Hz on 50 MHz in the first 30 minutes or so. This is a lot.
The best solution would be to feed an external GPS referenced signal into the transceiver, but where to get this stabilized 15,6 MHz from?
So I came THE other solution of putting in a more stable oscillator in form of a Temperature Controlled Oscillator (TCXO).
There a an option (03) available, where you must buy an expensive temperature controlled oscillator for far over 100€ for the original Kenwood equipment. Nowadays there are quite cheap equivalent types available through eBay. They all seem to originate from China. Prices of those parts vary from 12€ to about 50€. I chose to order one for 19€ where I thought, I could do nothing wrong with it. Worst case: perhaps it would not work. After 12 days (30 days were proposed) it arrived and installation was easy.

With a stable beacon signal I could see, that the drift has been reduced to about 5 Hz after 60 minutes. That is a factor of 24 times better than with the old crystal. And the resulting frequency is only 2 Hz away from where it should be on 50 MHz. This makes this man happy now :-)

Posted by Christoph Petermann

(Page 1 of 16, totaling 152 entries)
